Edelbrock 3702 Performer-Plus Camshaft Kit for 1976-95 Small-Block Chevrolet

Description

Edelbrock part #3702 Performer-Plus camshaft is designed for small-block Chevy 305-350 T.B.I & LG-4 V-8 applications. This Edelbrock cam kit produced 245 ft-lbs. of torque when used with #3701 intake and stock iron cylinder heads on a 350 engine. The camshaft will produce optimum torque from the low-end to the mid-range Performer-Plus camshafts match with Performer manifolds for vehicles operating from off-idle to 5500 rpm. This Performer-Plus is a smooth idling cam for daily drivers trucks vans RVs and 4x4s. You can expect a major improvement in throttle response and torque. All camshafts include flat tappet lifters assembly lube and instructions. Camshaft Specifications: – Duration @ .050 Intake: 194 degrees – Duration @ .050 Exhaust: 214 degrees – Lift @ Valve Intake: .398" – Lift @ Valve Exhaust: .442" – Lobe Separation: 112 Degrees – Intake Centerline: 107 Degrees – Idle Vacuum @ 1000 RPM's: 16"

Features

• Edelbrock products offer improved performance and aesthetics for a broad array of vehicles and engines. 'Proven performance' is the philosophy by which Edelbrock was founded and it continues to this day with the highest standards for performance and quality. Edelbrock core products are engineered manufactured and tested in the USA to ensure the best quality possible. This is further backed by some of the best warranties in the industry and a highly qualified technical support staff.
• Edelbrock products offer improved performance and aesthetics for a broad array of vehicles and engines. 'Proven performance' is the philosophy by which Edelbrock was founded and it continues to this day with the highest standards for performance and quality. Edelbrock core products are engineered manufactured and tested in the USA to ensure the best quality possible. This is further backed by some of the best warranties in the industry and a highly qualified technical support staff.

Specifications

Vehicle Fitment

1982-1984 Chevrolet Corvette; 1982-1992 Chevrolet Camaro; 1982-1992 Pontiac Firebird; 1987-1987 Chevrolet R10; 1987-1987 Chevrolet V10; 1987-1987 Chevrolet V20; 1987-1987 GMC R1500; 1987-1987 GMC V1500; 1987-1987 GMC V2500; 1987-1988 Chevrolet R10 Suburban; 1987-1988 Chevrolet R20; 1987-1988 Chevrolet R20 Suburban; 1987-1988 Chevrolet R30; 1987-1988 Chevrolet V10 Suburban; 1987-1988 Chevrolet V20 Suburban; 1987-1988 Chevrolet V30; 1987-1989 GMC R2500; 1987-1991 GMC Jimmy; 1987-1991 GMC R1500 Suburban; 1987-1991 GMC R2500 Suburban; 1987-1991 GMC R3500; 1987-1991 GMC V1500 Suburban; 1987-1991 GMC V2500 Suburban; 1987-1991 GMC V3500; 1987-1994 Chevrolet Blazer; 1987-1995 Chevrolet G10; 1987-1995 Chevrolet G20; 1987-1995 Chevrolet G30; 1987-1995 GMC G1500; 1987-1995 GMC G2500; 1987-1995 GMC G3500; 1988-1995 Chevrolet C1500; 1988-1995 Chevrolet C2500; 1988-1995 Chevrolet C3500; 1988-1995 Chevrolet K1500; 1988-1995 Chevrolet K2500; 1988-1995 Chevrolet K3500; 1988-1995 GMC C1500; 1988-1995 GMC C2500; 1988-1995 GMC C3500; 1988-1995 GMC K1500; 1988-1995 GMC K2500; 1988-1995 GMC K3500; 1989-1991 Chevrolet R1500 Suburban; 1989-1991 Chevrolet R2500 Suburban; 1989-1991 Chevrolet R3500; 1989-1991 Chevrolet V1500 Suburban; 1989-1991 Chevrolet V2500 Suburban; 1989-1991 Chevrolet V3500; 1989-1993 Chevrolet Caprice; 1990-1992 Cadillac Brougham; 1991-1992 Oldsmobile Custom Cruiser; 1991-1993 Buick Commercial Chassis; 1991-1993 Buick Roadmaster; 1991-1993 Chevrolet Commercial Chassis; and more – see compatibility chart

Installation Instructions (PDF)
